Overview

Modeling hierarchical tree structures in SQL databases has traditionally been difficult. At least until the introduction of Recursive Common Table Expressions (Recursive CTEs) that made it much simpler to craft queries to traverse a recursive path within a hierarchy, aka a tree structure.

A tree is an undirected, connected graph with no cycle, so when modeling product catalogs with categories for example, it's formally a special form of graph:

You don't need to use a graph database for that though. There are two main approaches to modeling tree structures in relational SQL databases:

Adjacency List Model
Nested Set Model

The Adjacency List Model with recursive CTEs provides the easiest approach. It's much less taxing on mutations of the tree structure, more performant and supports arbitrarily deep nestings / levels. The SQL is also much simpler and client code cleaner as well.

The Nested Set Model requires tracking two references per item instead of a single one in the adjacency model, making things less efficient and more difficult to implement in client code and SQL.

The Nested Set Model is not commonly used in SQL databases anymore since the introduction of recursive CTEs decades ago. That doesn't make it less interesting though, and it's likely still in use in many systems, in particular MySQL. Although completely unrelated to this, it's like exploring shortest path algorithms like Dijkstra's. Just of those things interesting to know a bit more about.

Let's look at an implementation of the nested set model using Spring Boot and CockroachDB to follow the historical order. We could have used the adjacency list model with recursive CTEs instead, but that's for a follow up post.

Source Code

The source code for this example is available in GitHub.

The Adjacency List Model

The adjacency list model is pretty straightforward. It's a parent-child relationship where each item in the table contains a pointer to its parent. The benefits are that it's simple, provides referential integrity and its also easy and efficient to update the structure using SQL.

The main drawback is that it performs poorly with deeply nested tree's (many levels), unless using recursive CTEs. Combined with CTEs, this is the preferred and portable approach to use in modern databases over the nested set model.

create table category
(
    id            int          not null default unordered_unique_rowid(),
    name          varchar(64)  not null,
    description   varchar(256),
    parent_id     int,

    primary key (id)
);

Listing all the categories:

select id,
       name,
       parent_id
from category order by name;

id	name	parent_id
109012213791195137	0-60	5980017278022057985
1854157069397262337	101-250	5980017278022057985
3771564610750251009	251-500	5980017278022057985
1342998511690711041	61-80	5980017278022057985
8686117704118304769	81-100	5980017278022057985
9138447991692328961	Anis	1692308957788635137
7371629562879541249	Argentina	9184328412896165889
4597412192419315713	Australia	9184328412896165889
7882788120586092545	Austria	3785638359585783809
1066449347072491521	Available in store	1942399474596052993
3447586912556285953	Box	1468043770094419969
5176406219513135105	Bread	1692308957788635137
888979374256422913	Butter	1692308957788635137
3175119135100370945	Champagne	1468043770094419969
5261939428061085697	Chardonnay	2664488342975152129
9124655717833506817	Country	null
939081920110919681	Dessert	1468043770094419969
3785638359585783809	Europe	9124655717833506817
7803834389618753537	Findings under 150	1942399474596052993
2379389375939346433	France	3785638359585783809
6464154237964386305	Germany	3785638359585783809
2664488342975152129	Grape	null
7704051510374825985	Honey	1692308957788635137
412442238685282305	Italy	3785638359585783809
4060217199367028737	Kanonkop	3346396658428805121
1692308957788635137	Label	null
9197698474289922049	Masi	3346396658428805121
4113521523081609217	Merlot	2664488342975152129
5410171187671334913	Miguel Torres	3346396658428805121
9184328412896165889	New World	9124655717833506817
5980017278022057985	Price	null
3346396658428805121	Producer	null
6128495328236929025	Recent News	1942399474596052993
4539709822193631233	Red	1468043770094419969
3694686757736153089	Riesling	2664488342975152129
2098758824158822401	Rose	1468043770094419969
2381641175753031681	South Africa	9184328412896165889
2032612204631818241	Spain	3785638359585783809
6512286458981908481	Sparkling	1468043770094419969
1942399474596052993	Special	null
1468043770094419969	Types	null
3501067158131310593	Vanilla	1692308957788635137
7836344749428834305	White	1468043770094419969
4807111050068754433	Young	1692308957788635137

Tree listing using recursive CTEs

Just to show the usefulness of recursive CTEs, this query will list the entire tree structure in one single query:

with recursive category_tree (id, name, parent_id, level, path) as
                   (select id,
                           name,
                           parent_id,
                           0,
                           concat('/', name, '/')
                    from category
                    where parent_id is null -- anchor

                    union all

                    select c.id,
                           c.name,
                           c.parent_id,
                           ct.level + 1,
                           concat(ct.path, c.name, '/')
                    from category c
                             join category_tree ct
                                  on c.parent_id = ct.id)
select *
from category_tree
order by path;

To filter down on a particular sub-tree name, just change the CTE anchor query:

with recursive category_tree (id, name, parent_id, level, path) as
                   (select id,
                           name,
                           parent_id,
                           0,
                           concat('/', name, '/')
                    from category
                    where parent_id is null
                      and name = 'Label' -- anchor

                    union all

                    select c.id,
                           c.name,
                           c.parent_id,
                           ct.level + 1,
                           concat(ct.path, c.name, '/')
                    from category c
                             join category_tree ct
                                  on c.parent_id = ct.id)
select *
from category_tree
order by path;

Now, forget about the CTE approach and let's do it the hard way.

The Nested Set Model

In the Nested Set Model, each item in the table contains two pointers to track the containment of sublevels. This allows for a query to extract sub-trees in one single query rather than use recursion or one self-join per level, which is the drawback of the adjacency model without a recursive CTE.

As such, a tree hierarchy is not expressed as vertices and edges in a parent-child relationship, but instead as nested containers. Instead, picture the wine catalog like this:

Let's update the schema:

create table category
(
    id            int          not null default unordered_unique_rowid(),
    name          varchar(64)  not null,
    description   varchar(256),
    lft           int          not null,
    rgt           int          not null,
    parent_id     int,

    primary key (id)
);

select id,
       name,
       lft,
       rgt
from category order by name;

id	name	lft	rgt
109012213791195137	0-60	2	3
1854157069397262337	101-250	4	5
3771564610750251009	251-500	6	7
1342998511690711041	61-80	8	9
8686117704118304769	81-100	10	11
9138447991692328961	Anis	14	15
7371629562879541249	Argentina	65	66
4597412192419315713	Australia	67	68
7882788120586092545	Austria	53	54
1066449347072491521	Available in store	28	29
3447586912556285953	Box	36	37
5176406219513135105	Bread	16	17
888979374256422913	Butter	18	19
3175119135100370945	Champagne	38	39
5261939428061085697	Chardonnay	82	83
9124655717833506817	Country	51	72
939081920110919681	Dessert	40	41
3785638359585783809	Europe	52	63
7803834389618753537	Findings under 150	30	31
2379389375939346433	France	55	56
6464154237964386305	Germany	57	58
2664488342975152129	Grape	81	88
7704051510374825985	Honey	20	21
412442238685282305	Italy	59	60
4060217199367028737	Kanonkop	74	75
1692308957788635137	Label	13	26
9197698474289922049	Masi	76	77
4113521523081609217	Merlot	86	87
5410171187671334913	Miguel Torres	78	79
9184328412896165889	New World	64	71
5980017278022057985	Price	1	12
3346396658428805121	Producer	73	80
6128495328236929025	Recent News	32	33
4539709822193631233	Red	42	43
3694686757736153089	Riesling	84	85
2098758824158822401	Rose	44	45
2381641175753031681	South Africa	69	70
2032612204631818241	Spain	61	62
6512286458981908481	Sparkling	46	47
1942399474596052993	Special	27	34
1468043770094419969	Types	35	50
3501067158131310593	Vanilla	22	23
7836344749428834305	White	48	49
4807111050068754433	Young	24	25

The left and right values for each item is determined by traversing the graph starting from the root (there are multiple roots here) and descending to each leaf node, before assigning a number to the right and moving on. Gradually progressing from left to right. This is known as the modified preorder tree traversal (MPTT) algorithm.

Category structure example with the left and right numbers laid out:

Tree listing using Nested Set Model

To show the nested set model in action, this is the query that will list the entire tree structure using a cross join:

select category0_.name as col_0_0_, count(category1_.name) - 1 as col_1_0_
from category category0_
         cross join category category1_
where category0_.lft between category1_.lft and category1_.rgt
group by category0_.name, category0_.lft
order by category0_.lft;

col_0_0_	col_1_0_
Price	0
0-60	1
101-250	1
251-500	1
61-80	1
81-100	1
Label	0
Anis	1
Bread	1
Butter	1
Honey	1
Vanilla	1
Young	1
Special	0
Available in store	1
Findings under 150	1
Recent News	1
Types	0
Box	1
Champagne	1
Dessert	1
Red	1
Rose	1
Sparkling	1
White	1
Country	0
Europe	1
Austria	2
France	2
Germany	2
Italy	2
Spain	2
New World	1
Argentina	2
Australia	2
South Africa	2
Producer	0
Kanonkop	1
Masi	1
Miguel Torres	1
Grape	0
Chardonnay	1
Riesling	1
Merlot	1

To filter down on a particular sub-tree name:

SELECT node.name AS name, (COUNT(parent.name) - (sub_tree.depth + 1)) AS depth
FROM category AS node,
     category AS parent,
     category AS sub_parent,
     (SELECT node.name, (COUNT(parent.name) - 1) AS depth
      FROM category AS node,
           category AS parent
      WHERE node.lft BETWEEN parent.lft AND parent.rgt
        AND node.name = 'Label'
      GROUP BY node.name, node.lft
      ORDER BY node.lft) AS sub_tree
WHERE node.lft BETWEEN parent.lft AND parent.rgt
  AND node.lft BETWEEN sub_parent.lft AND sub_parent.rgt
  AND sub_parent.name = sub_tree.name
GROUP BY node.name, node.lft, depth
ORDER BY node.lft;

name	depth
Label	0
Anis	1
Bread	1
Butter	1
Honey	1
Vanilla	1
Young	1

The subquery could also be extracted to a CTE to improve readability a bit by rewriting the query:

with sub_tree as (SELECT node.name, (COUNT(parent.name) - 1) AS depth
                  FROM category AS node,
                       category AS parent
                  WHERE node.lft BETWEEN parent.lft AND parent.rgt
                    AND node.name = 'Label'
                  GROUP BY node.name, node.lft
                  ORDER BY node.lft)
SELECT node.name AS name, (COUNT(parent.name) - (sub_tree.depth + 1)) AS depth
FROM category AS node,
     category AS parent,
     category AS sub_parent,
     sub_tree
WHERE node.lft BETWEEN parent.lft AND parent.rgt
  AND node.lft BETWEEN sub_parent.lft AND sub_parent.rgt
  AND sub_parent.name = sub_tree.name
GROUP BY node.name, node.lft, depth
ORDER BY node.lft;

Demo Project

To explore the nested set model in a semi-realistic context, let us use a service with the following product catalog schema:

The entity model contains of products, product variations with attributes and categories organized into a tree structure. A fairly common layout for an online webshop and similar.

The main artifacts of interest are:

Category - Domain entity that models a hierarchy of categories.
JpaCategoryRepository - The JPA implementation using Criteria API to craft the nested set model operations.
ProductCatalogTest - Functional tests of the product catalog.

This implementation is using JPA with Hibernate and partly also the dreaded but type safe Criteria API which happens to be fairly suitable for this problem domain.

To take one query example, finding all products within a given non-leaf category such as "Europe" that has several country categories below it:

Client code:

    @Test
    @Order(11)
    @Transactional
    @Commit
    public void whenFindingBeveragesByInheritedCategory_expectResults() {
        // Expects beverages under 'Europe'
        Category category = categoryRepository.getByTypeAndName(DistrictCategory.class, "Europe");
        List<Product> products = productRepository.findByCategory(category);
        Assertions.assertEquals(products.size(), 1);
    }

SQL:

First for the category:

select distinct districtca0_.id          as id2_1_,
                districtca0_.description as descript3_1_,
                districtca0_.lft         as lft4_1_,
                districtca0_.name        as name5_1_,
                districtca0_.parent_id   as parent_i8_1_,
                districtca0_.rgt         as rgt6_1_,
                districtca0_.country     as country7_1_,
                categorize1_.category_id as category1_0_0__,
                categorize1_.expires_at  as expires_2_0_0__,
                categorize1_.product_id  as product_3_0_0__
from category districtca0_
         left outer join categorized_product categorize1_ on districtca0_.id = categorize1_.category_id
where districtca0_.category_type = 'DISTRICT'
  and districtca0_.name='Europe';

Then for the products in that category:

select product2_.id          as id1_2_,
       product2_.description as descript2_2_,
       product2_.name        as name3_2_,
       product2_.sku_code    as sku_code4_2_
from category category0_
         inner join categorized_product categorize1_ on category0_.id = categorize1_.category_id
         inner join product product2_ on categorize1_.product_id = product2_.id
where category0_.lft between 52 and 63;

Conclusion

Modeling tree structures in SQL databases used to be a pain in the past until recursive CTEs were introduced. Before that, the nested set model offered a more efficient method in contrast to the adjacency list model without CTEs.

Model Tree Structures with CockroachDB

Comments

More from this blog

Handling Null Values Efficiently with Spring Named Parameter Binding

Multi-active systems

User defined composite types

Transaction timeouts in CockroachDB

One-Phase Commit Transaction Strategy

Overview

Source Code

The Adjacency List Model

Tree listing using recursive CTEs

The Nested Set Model

Tree listing using Nested Set Model

Demo Project

Conclusion

Command Palette

Comments

More from this blog

Overview

Source Code

The Adjacency List Model

Tree listing using recursive CTEs

The Nested Set Model

Tree listing using Nested Set Model

Demo Project

Conclusion
